Description
CSA728MFM201-8 stamped steel bearing is a 2-bolt vibration-damping flush mount flange bearing designed for light-duty industrial and agricultural applications. The superior quality stamped steel housing encases a performance C3 precision 1/2″ insert bearing that utilises an eccentric locking collar for securing onto a shaft. The bearing unit features a rubber cushion made from high-quality rubber for decreasing vibration. CSA728MFM201-8 bearings are more economical than their cast counterparts but offer excellent performance in bearing applications; the two-bolt flange stamped steel housing allows for great mounting when the shaft is positioned perpendicular to the bearing. Utilizing two mounting holes, the CSA728MFM201-8 1/2″ bearing has incredible holding power, stability, and mounting position flexibility. Additionally, our CSA728MFM201-8 stamped steel bearing features a zinc plated housing for added protection against the elements in corrosive or outdoor applications. For more information or to get a quote on our flush mount CSA728MFM201-8 bearing, contact our customer support team, and we will be happy to assist you!
CSA728MFM201-8 Bearing Dimensions
- Bearing Unit Part #: CSA728MFM201-8
- Bearing I.D: 1/2″
- Dimension (a): 4″
- Dimension (e): 3″
- Dimension (b): 2″
- Dimension (D): 29/64″
- Dimension (E): 3/4″
- Dimension (L): 1.126″
- Bolt Size: 1/4″
- Bearing Part #: CSA201-8
- Housing With Rubber Insert Part #: 728-2-MFM
- Weight: 0.30 LBS
