Taper Bushed D12Btb18 Sprocket For #12B Chain Applications

Description

This D12BTB18 sprocket is a metric taper bushed style roller chain sprocket manufactured under ISO and British Standard 228. and is made to accept a 2012 taper bushing. Our D12BTB18 sprockets are made with reliability and performance in mind, so we use high-quality carbon steel (CS) and have the sprocket precision cut to ensure maximum performance and wear life. We also offer upgrades on our D12BTB18 sprockets such as black-oxide coatings and heat-treated hardened teeth, though we often have these specific sprockets with those features already added right off the shelf. Besides the 18 tooth sprocket, we also stock a high-quality 12B-2 roller chain, 2012 bushings, and a wide array of roller chain accessories. For more information or to get a quote on taper bushed D12BTB18 sprockets, please contact us and one of our sales team members will be happy to assist you.

D12BTB18 Sprocket Dimensions

• Sprocket Size: D12BTB18
• Tooth Count: 18
• Pitch Diameter: 109.71mm
• Bushing Size: 2012
• Maximum Bushing Bore: 50.8mm
• Dimension (L): 31.8mm
• Dimension (H): 90.0mm
• Sprocket Weight: 1.05 kg
• Bushing Weight: 0.59 kg
